Ncstudio Controller AC220V 24000rpm Stone Cutting CNC Router

Ncstudio Controller AC220V 24000rpm Stone Cutting CNC Router
Ncstudio Controller AC220V 24000rpm Stone Cutting CNC Router

Large Image :  Ncstudio Controller AC220V 24000rpm Stone Cutting CNC Router

Product Details:

Model Number: UT3020
Detailed Product Description
XYZ Working Size: 300mm X 250mm X 140mm Max Feeding Height: 150mm
Spindle Power: 1.5KW / 2.2KW Tool Diameter: 3.175 / 4 / 6mm
Max Spindle Speed: 6000-24000RPM Max.Cutting Speed: 4000mm Per Min
Repositioning Accuracy: 0.01mm Controller: Ncstudio
High Light:

6000rpm Stone Cutting CNC Router

,

AC220V Stone Cutting CNC Router

,

24000rpm Stone Cutting CNC Router

UT3020 CNC stone engraving machine with CE



Stone Cutting CNC Router 3D Stone Carving Machine Engraving Marble Granite is suitable for stone lettering, relief engraving, line engraving, cutting, hollowing out, etc. Various stones such as marble, granite, jade, bluestone, sandstone, and material like ceramics, glass, acrylic, organic glass, PVC board, aluminum sheet, bamboo, etc. are all suitable to work with.


Independent water recirculation cooling system and stainless steel sink and stainless steel sheet metal parts, protecting the entire frame from corrosion and rust.


The whole anti-dust and waterproof structure can better protect the linear rails and gear&rack.(4 small jets of water are pointed at the router bit and this captures almost all fine stone dust in the water, which then flows to a collection reservoir where the stone particles settle on the bottom.), greatly decreasing the fault in engraving an extending the service life of the machine.



CNC stone engraving machine with CE
1. CE certificate
2. 4.5kw water cooling spindle
3. stepper motor 118



1. -Application

This-series-of-models-mainly-used-for-heavy-weight-of-the-tile,-bluestone,marble,-granite,-white- marble,-sandstone,-glass-engraving,-metals-engraving-and-so-on.-

-

2. -Configuration:

-- 1.4.5kw-water-cooling-spindle-

-- 2.stepper-motor-118-

-- 3.-Taiwan-Yako-driver-2811

-- 4.the-whole-steel-structure-

-- 5.all-axises-imported-Twaiwan-Hiwin-Linear-sqaure-orbit-.

-- 6.ballscrew-transimssion-

-- 7.Original-TYPE3-UCANCAM-software-

-- 8.DSP-Control-system-(NC-studio-control-system-)

-

3. Features

1. X,Y,-Z-three-axises-all-use-imported-square-orbits-.heavy-loading,-stable-working,-high-precision-and-long-lifetime-.

2. It-also-equips-with-water-groove-and-dustproof-structure.It-can-protect-the-machine-and-make-it-long-operating-life--

3. Water-cooling-constant-torque-spindle-with-the-imported-bearings,-high-power-and-low-noise.--

4. The-transducer-with-stable-output-signals

5. Fully-sgielded,bending-circuity,-and-imported-electronic-components.

6. Double-drivers-to-drive-y-axis,-motivity-is-more-stronger

7. Whole-seamless-steel-structure,can-load-weight-up-to-1000kg/

8. Well-compatibility,-compatible-sofetware-CAD/CAM,-such-as-Type-3,-Artcam,Castmate, UCANCAM-,Coredraw

-

4. Parameters:

Model UT3020
XYZ working size 300mm X 250mm X 140mm
Max Feeding Height 150mm
Spindle Power 1.5KW / 2.2KW
Tool Diameter 3.175 / 4 / 6mm
Max Spindle Speed 6000-24000RPM
Max.Cutting Speed 4000mm per min
Repositioning Accuracy 0.01mm
Controller Ncstudio
File Format PLT , G CODE
Voltage AC220V



Ncstudio Controller AC220V 24000rpm Stone Cutting CNC Router 0
