1200×900mm 1325 CO2 Glass Tube Laser Cutting Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | Unitec |
| Certification: | CE |
| Model Number: | UT1325CL150 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|
|
Detail Information |
|||
| Max Table Loading Weight (kg): | 200 | Max Acrylic Cut Thickness（mm）: | 40 |
|---|---|---|---|
| Max Location Speed (m/min): | 20 | X\Y Location Accuracy（mm/m）: | ±0.025 |
| X\Y Repeat Location Accuracy（mm）: | ±0.005 | Voltage (50/60Hz): | 220V Single Phase |
| Total Power Consumption: | 2KW | Assistant Cutting Air Pressure (MPa): | 0.6 |
| High Light: | 1200×900mm Tube Laser Cutting Machine,40m/min Tube Laser Cutting Machine,1200×900mm Glass Laser Cutting Machine |
||
Product Description
UT1325CL150 1325 CO2 glass tube Laser Cutter Cutting Machine
Application range:
3000W Stainless steel silver metal tube pipe CNC fiber laser cutting machine: Suitable for stainless steel, carbon steel, silicon steel, aluminum alloy, titanium alloy, galvanized steel, pickle plate, aluminum-plating Zinc plate, metallic copper and other metals.
Specially used for cutting 0.5-22mm carbon steel sheets (pipes), 0.5-10mm stainless steel sheets, galvanized steel(pipes), electrolytic zinc-coated steel sheet(pipes), silicon steel(pipes) and other kinds of thin metal sheets and pipes. Range of pipe diameters: 20-220mm.
Applications and Materials
Signmaking Industry: Acrylic, MDF, Wood,etc
| Item | Description | Marks |
| Working Size | X:1200mmY:900mm | Machine body produced by high accuracy machine center |
| Laser Cutting Head | High Accuracy Head with quick loading function | With Double Focus system |
|
Mechanical Driving System |
X/Y Ball Screw | Taiwan TBI |
| X/Y/Z Linear Guide | Taiwan TBI | |
| Special Cool System |
Compressor Overloading Alarm Temperature Overheat Alarm Temerature Control Accuracy ±0.5℃ |
Guangzhou Teyu |
| Motion Control System | Off line Control | Ruida |
| X ,Y Servo Driver | MR-JE-40A | Japan Mitsubishi |
| Z driver | DMD-402A | LEETRO |
| Main Contactor | LS | Imported from Korea |
| Origin Switch | PANASONIC | Japan Panasonic |
| Laser Tube Power (W) | 150W | |
| Laser Beam Quality | M2≤1.1 | |
| Working Size(mm) | 1200×900mm | |
| Max Table Loading Weight (kg) | 200 | |
| Max Acrylic Cut Thickness(mm) | 40 | |
| Max Location Speed (m/min) | 20 | |
| XY Location Accuracy(mm/m) | ±0.025 | |
| XY Repeat Location Accuracy(mm) | ±0.005 | |
|
Travel Size
|
X-(mm) | 1200 |
| Y-(mm) | 900 | |
| Z-(mm) | 40 | |
| Voltage (50/60Hz) | 220V single phase | |
| Total Power Consumption | 2KW | |
| Assistant Cutting Air Pressure (MPa) | 0.6 | |
Highlights
1. Integral welded big square steel pipe, mounting surface of guide ail and rack processed by high-precision milling machine, ensure the machine running stability
2. Driven by Taiwan TBI ball screw with TBI linear Guide
3. Japan Mitsubishi Servo motor and driver
4. Reliable CO2 glass laser tube
5. Controller with multi language options: English, Italy, Germany, France, Spanish, Arabic,etc.
